規格
| 種類 | Upsampling CD/SACD Transport. |
| 顏色 | Silver or Black. |
| 機械承盤結構 | Dual laser CD/SACD mechanism. |
| 尺寸 | 444mm (17.5”) long x 435mm (17.2”) deep x 178mm (7.0”) high. Allow extra depth for cable connectors. Allow space for air flow around the unit. |
| 重量 | 20.6kg (45.3lbs). |
| 數位輸出 | Dual AES interface on 2x 3-pin male XLR connectors (AES1+2). While an SACD is playing, the interface outputs encrypted DSD data. While a CD is playing, the Settings > Upsample Mode menu page sets the interface to output either encrypted DSD data (1 bit at 2.822MS/s) or DXD data (24 bits at 352.8kS/s) or DSDx2 data (1 bit at 5.644MS/s). AES interface on 3-pin male XLR connector (AES3), outputs 16/44.1 data, whether a CD or SACD is playing. 2x SPDIF on 1x RCA Phono and 1x BNC connectors. Each outputs 16/44.1 data, whether a CD or SACD is playing. |
| 時鐘輸入/出 | Word Clock Output on 1x BNC connector. With the transport in Master mode, a TTL-compatible 44.1kHz word clock derived from the internal crystal oscillator is available on this output. Word Clock Input on 1x BNC connector, accepts standard word clock at 44.1, 88.2 or 176.4kHz. Sensitive to TTL levels. Lock range is +/-300ppm. |
| 時鐘精度度 | The calibration accuracy when shipped is +/-10ppm, (not temperature compensated). |
| 軟體升級 | Updates are loaded directly from CD-R. |
| 控制方式 | dCS Premium Remote handset (not supplied with Rossini Transport as standard. Via the Rossini app, RS232 app or a third party device. |
| 電源供應 | Factory set to either 100, 115/120, 220 or 230/240V AC, 50/60Hz. |
| 消耗功率 | 16W typical / 50W maximum. Consumes less than 0.5W when powered down from the front panel. |
| 操作系統 | Windows Vista / 7 / 8.1 / 10, Mac OSX 10.10. dCS USB driver is required for Windows in Audio Class 2 Mode. |
