規格
產品尺寸/重量 | 121.5mm (H) x 220mm (W) x 339mm (D) 7.4kg |
類比輸出 | • 1 x stereo pair 3 pin balanced XLR • 1 x stereo pair unbalanced RCA |
左右聲道串音干擾 | Better than –115dB0, 20Hz-20kHz |
支援串流平台及播放技術 | • UPnP • Qobuz • Deezer • Tidal • Internet Radio • Spotify • Apple AirPlay 2 (support at 44.1 or 48kS/s) • RoonReady |
數位輸入 | • 2 x AES/EBU on 3 pin XLR 44.1-384kS/s • 1 x S/PDIF BNC Coax 44.1-192kS/s • 1 x S/PDIF on RCA 44.1-192kS/s • 1 x Toslink 44.1-96kS/s • 1 x USB Type B 44.1-384kS/s, PCM and DSD, DSDx2 in Async Mode • 1 x USB Type A connector for mass storage devices (navigated using Mosaic) |
頻率響應(set to filter 1) | • Fs = 44.1 or 48kS/s +/-0.1dB, 10Hz-20kHz • Fs = 88.2 or 96kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >38kHz • Fs = 176.4 or 192kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >67kHz • Fs = 352.8 or 384kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >100kHz • DSD64 +/-0.1dB, 10Hz-20kHz -3dB @ >90kHz • DSD128 +/-0.1dB, 10Hz-20kHz -3dB @ >100kHz |
殘留雜音(6v output setting) | • 16-bit data: Better than –96dB0, 20Hz-20kHz unweighted • 24-bit data: Better than –113dB0, 20Hz-20kHz unweighted |
支援音源格式及取樣頻率 | • 44.1-384kHz • DSD 64, 128 • Native DSD + DoP (input dependent) • FLAC, WAV, AIFF, MQA |
