規格
產品尺寸/重量 | 121.5mm (H) x 220mm (W) x 356mm (D) / 7.5kg |
耳機輸出介面 | • 1 x dual 3-pin balanced XLR, right and left channel • 1 x single 4-pin balanced XLR • 1 x single 1⁄4” (6.35mm) headphone jack |
訊噪比 | 110dB 20Hz-20kHz A-weighted (referenced to 6V rms balanced input and output) |
類比輸入 | • 1 x stereo pair unbalanced RCA, input impedance 48kΩ • 1 x stereo pair unbuffered balanced XLR, input impedance 16kΩ • 1 x stereo pair buffered balanced XLR, input impedance 96kΩ |
總諧波失真 | under 0.005% @ 1kHz 6V rms balanced output into 30Ω (80kHz bandwidth) |
頻率響應 | 1Hz-100kHz Better than +0/-3dB |
輸出功率 | • 2W (30Ω/balance) • 0.48W (300Ω/balance) • 1.6W (30Ω/unbalanced) • 0.2W (300Ω/unbalanced) |
