規格
| 輸出電壓 | 220 – 240 V (50 – 60 Hz) 100 – 120 V (50 – 60 Hz) |
| 消耗功率 | ＜0.5 W Standby idle 150 W max 1600 W |
| 輸出 | 2 pairs Cu-terminal, gold plated |
| 增益 | – 31 dB bis + 42 dB |
| 輸出功率 | 125 W @ 8 Ω 250 W @ 4 Ω 500 W @ 2 Ω |
| 脈衝功率 | ＞5,000 W |
| 頻率響應 (– 3 dB) | 0 – 800 kHz |
| 總諧波失真 | ＜0.001% at 50 W @ 4 Ω (20 Hz – 20 kHz) |
| IM distortions | ＜0.005 % SMPTE ＜0.0006 CCIR |
| 訊噪比 | ＞120 dB (5 W @ 1 kHz) |
| 聲道分離度 | ＞110 dB @ 1 kHz |
| 阻尼因子 | ＞10 000 |
| 最大輸出電流 | 45 A (limited) |
| 輸入規格 | 2 × balanced (XLR) 2 × unbalanced (RCA) 1 × Phono (RCA) |
| 輸入阻抗 | 3 kΩ balanced (XLR) 3 kΩ unbalanced (RCA) Phono configurable |
| 尺寸 | 442 × 350 × 448 mm (W × H × D) |
| 重量 | approx. 40 kg |
| LINK (remote turn-on) | 12 V control signal |
