規格
| 輸出電壓 | 100 – 120 V (50 – 60 Hz) 220 – 240 V (50 – 60 Hz) |
| 消耗功率 | ＜0.5 W standby 100 W device in operation |
| 類比輸出 | 1 × balanced (XLR) 1 × unbalanced (RCA) |
| 頻率響應 | 0 – 200 kHz (DXD) |
| 全頻總諧波失真 | ＜0.002% (20 Hz – 20 kHz) |
| 訊號雜訊比 | ＞140 dB |
| 聲道分離度 | ＞130 dB |
| 輸出阻抗 | 10 Ω balanced (XLR) 10 Ω unbalanced (RCA) |
| 輸出電壓 | 4 VRMS balanced (XLR) 2 VRMS unbalanced (RCA) |
| 輸出電流最大值 | 0.2 A (limited by protection circuit) |
| 音量控制範圍 | 0 to – 79 dB in 1 dB steps |
| 數位輸入 | AES/EBU, SPDIF-RCA, Optical, USB, Network |
| 數位輸出 | AES/EBU, SPDIF-RCA, Optical |
| 數位格式 | WAV, AIFF, FLAC, ALAC, DSF, DFF, DXD, MP3, AAC |
| 位元深度/取樣最大值 | AES/EBU: 24 bit/192 kHz SPDIF: 24 bit/192 kHz Optical: 24 bit/96 kHz USB: 24 bit/384 kHz, 1 bit/5.64 MHz Network: 24 bit/384 kHz, 1 bit/5.64 MHz |
| 尺寸 | 442 × 143 × 448 mm (W × H × D) |
| 重量 | approx. 20 kg |
| LINK (remote turn-on) | 12 V control signal |
| USB 驅動 | v1.22c for Win7 v1.611 for Win7 v2.26 for Win10 |
